Transmission Electron Microscopy Laboratory

Transmission Electron Microscopy Lab
Thermo Fisher Scientific Talos F200i

Thermo Fisher Scientific Talos F200i features:

  • High brightness X-FEG emitter
  • High-tension: 80 - 200 kV
  • HAADF detector for Z-contrast (Segmented Panther STEM)
  • ADF, BF detectors
  • Videocamera (Flucam)
  • 4k CMOS camera for in situ and operando TEM (CETA S)
  • Dual Bruker XFlash 6 | 100 EDS detectors
  • Fischione tomography sample holder and software
  • CompuStage single-tilt holder
  • CompuStage low-background double-tilt holder
  • High-visibility low-background double-tilt holder
  • Protochips Poseidon Select LP-TEM holder including heating and electrochemistry option and pumping system
  • DENSsolutions Stream LP-TEM holder including heating and electrochemistry option and differential pumping system
  • Gamry Reference 620 potentiostat for operando TEM

Sample preparation tools:

  • PIE Scientific Tergeo EM Plasma Cleaner (H2O, ambient air, Ar)
  • Leica s9D stereo microscope

Contact Persons

Dr.-Ing. Andreas Hutzler

Team leader "Nanoanalysis of Electrochemical Processes"

    Building HIERN-Cauerstr /
    Room 4009
    +49 9131-12538174
    E-Mail

    M.Sc. Andreas Körner

    Doctoral Researcher

      Building HIERN-Cauerstr /
      Room 4030
      +49 9131-12538162
      E-Mail

      Dr.-Ing. Birk Fritsch

      Postdoctoral Researcher

        Building HIERN-Cauerstr /
        Room 4009
        +49 9131-12538109
        E-Mail

        Lucía Morales

        Doctoral Researcher

          Building HIERN-Cauerstr /
          Room 4003
          +49 9131-12538174
          E-Mail
